4 inch quick release v band pipe clamp for turbo/blow off valves

FOB Reference Price:Get Latest Price
US $5-20 / Sets | 20 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangxi, China (Mainland)
Brand Name:
TMHOLD
Size:
12"
loge:
OEM
delivery time:
within 15 days
package:
one set in a plastic bag
usage:
turbo exhaust muffler downpipe
Type:
Exhaust Pipe
Model Number:
THV
SupplyAbility
SupplyAbility:
10000 Set/Sets per Day
Packaging & Delivery
Packaging Details
one set in a plastic bag and several bags in a carton or as you requested.
Port
ningbo or shanghai
Lead Time :
within 15 days after receiving the pre-payment

Specifications

1)size:from 2.0 inch to 12 inch
2)material:304ss or 316ss
3))one v band clamp with two flanges
4) v Clamp made for 8 years

  3.25 inch quick release v band exhaust clamp for turbo/blow off valves



Features



  • Extra Heavy gauge precision formed retainers
  • .050 rounded edge flat outer band for added strength
  • 431 stainless steel heat treated T- Bolt for superior strength & thread life at elevated temperatures
  • Silver plated 347 stainless “Tall Beam” style nut for maximum longevity
  • Clamps are date coded for traceability
  • Common sense size numbering – Clamp # equals nominal flange clamping diameter or O.D.
  • Both Quick Release Latch & T-Bolt styles available in many sizes



V band Couplings offer effective fastening solutions in a wide range of applications including pumps, engines, exhaust systems, filters, and food and chemical processing equipment. Because V-Band Couplings can be easily assembled and disassembled, they are often used on equipment that requires frequent service or maintenance,The most adaptable and reliable way to bond your exhaust components is to use a V-band assembly Kit. With a V-band kit, you manage to install and change your exhaust parts with no trouble, as well as maintaining the durability and strength of an exhaust .





Material:   304ss or 316ss





Bandwidth:19mm,22mm,25mm





Specification as below table;



Item No.Clamp size(inch)Screw(mm)Bandwidth(mm)Flange inner size(mm)Net weight(clamp)/gNet weight(flange)/gMaterialSurface
THV2002.0'M61951.6140104SUS 304     Polished
THV2252.25'57.9149114
THV2502.5'64.3158122
THV2752.75'70.6176133
THV3003.0'M82577231150
THV3253.25'83.3254163
THV3503.5'89.7263171
THV4004.0'102.4179192
THV5005.0'127.8329238
THV100010"M10254697448
THV120012"304.8799556





Application Examples







Made to order against buyer's samples or drawings

Processing
